1. Introduction
Parker filter provides a filtering scheme which can effectively replace deep and other inner diameter 2-1/2″forms in heavy- flowing situations,such as anti-osmosis pre-filtering and similar efficiency-catering occasions.Each park series filter can process flow of 1300 liter/minute,which significantly reduces the filter quantity and size.The capacity of a park filter is equivalent to 10 filters with diameter 2-12”,length 40”.Positively charged type O sealing ring and a built-in handle make the filter installation fast, safe and convenient.
2. Application Fields
Pretreating of RO cartridge filtration,seawater desalination
Filtration of condensed water in power plants
Filtration of bulk drug,solvent,and water in bio- pharmacy industry
Filtration of bottled water,liquid glucose,edible oil,juice, softdrink and milk
Painting,petrochemical industry
Micro-electronics,film,fiber,resin
3. Product Properties
Great capacity of impurity and long life.
Less replacement saves labor cost.
Sealed interface reduces the danger of bypass flow and improve the efficiency of filtering.
Easier installment and lower labor cost
They are applied in various fields with their extensive chemical applications.
4.Technical Specifications
| Material | |
|---|---|
| Filter Material |
Glass Fiber Polypropylene (PP) |
| Support / Diversion Layer | Polypropylene (PP) |
| End Cap | Reinforced Polypropylene with Glass Fiber |
| Seal Ring Material |
EPR (Ethylene-Propylene Rubber) Silicone Rubber Nitrile Rubber Fluorine Rubber |
| Performance of Filter Elements | |
| Filtering Accuracy | 1 μm / 4.5 μm / 6 μm / 10 μm / 20 μm / 40 μm / 70 μm / 100 μm |
| Highest Operating Temperature | 82 ℃ |
| Maximum Pressure Drop | 3.4 bar @ 82 ℃ |
| Recommended Maximum Filtering Water Flow | 1300 LPM |
