1. Introduction
It’s designed for a variety of container which can hold 1 to 37 filter elements.It can meet a variety of flow rate demands and the hardware of which has a price competitive advantage.The large diameter of Filter design increases the filter area and can greatly reduce the amount of filter elements and the shell size.
2. Application Fields
RO cartridge filtration,desalination pretreatment
The filtration of Power plant condensate water
Raw material drug,solvents and water filtration in biopharmaceutical industry
Filtration for bottled water,liquid glucose,edible oil,juice,soft drink and milk
Paints,coatings,petrochemical
Microelectronics,films,fibers,resin
3. Product Properties
High pollutant assimilative capacity can prolong the service life and reduce the cost
- Reduce the amount of replacement filter elements and decrease labor costs
- The design of seal interface can reduce the risk of bypass flows and increase the filtration efficiency
- Easier installment and lower labor costs
- Wide chemical applicability can be applied to a variety of fields
4.Technical Specifications
| Material | |
|---|---|
| Filter Material |
Glass Fiber Polypropylene (PP) |
| Support / Diversion Layer | Polypropylene (PP) |
| End Cover | Glass Fiber Reinforced Polypropylene |
| Seal Ring |
EPR PTFE Fluororubber (FKM) |
| Filter Element Performance | |
| Filtering Accuracy | 1 μm / 3 μm / 5 μm / 10 μm / 20 μm / 50 μm / 70 μm |
| Highest Operating Temperature | 80 ℃ |
| Maximum Pressure Drop | Folding Glass Fiber: 3.4 bar @ 20 ℃ |
| Recommended Pressure Drop for Replacement | 2.4 bar @ 20 ℃ |
| Maximum Water-Carrying Capacity | 1300 L/min |
