INDUSTRIAL PLEATED FILTER CARTRIDGES
PP / PES Pleated Filter Cartridges · 1–100 μm · DOE / 222 / 226
For RO Pretreatment, Process Water and Industrial Liquid Filtration
Larger Filtration Area
Lower Pressure Drop
Longer Service Life
OEM & Replacement Available
Our industrial pleated filter cartridges are designed for liquid filtration applications requiring larger filtration area, stable pressure drop and reliable particle removal. Available in PP, PES and optional PTFE media, these cartridges are commonly used in RO pretreatment, process water, food and beverage, chemical process and power plant filtration systems.
Common specifications
| Micron Ratings | |||
|---|---|---|---|
| 0.2 μm | 0.45 μm | 1 μm | 10 μm |
| 20 μm | 50 μm | 75 μm | 100 μm |
| Length | |||
|---|---|---|---|
| 10" | 20" | 30" | 40" |
| End Cap Options | |||
|---|---|---|---|
| DOE | 222 | 226 | Fin / SOE |
| Material |
|---|
| PP (Polypropylene) |
| PES (Polyethersulfone) |
| PTFE (Optional) |
| Filtration Type |
|---|
| Nominal (Depth) |
| Absolute (Membrane) |
Select by application
RO Pretreatment
Protect RO membranes from particles, colloids and upstream fluctuations.
Recommended:
PP Pleated, 1–5 μm
PROCESS WATER
Stable filtration for cooling water, circulating water and general industrial liquids.
Recommended:
PP Pleated, 5–20 μm
FOOD & BEVERAGE
Reliable filtration for food, beverage and beverage processes.
Recommended:
PES / PP Pleated, 0.2–5 μm
CHEMICAL PROCESS
Filtration for a wide range of chemicals and process liquids.
Recommended:
PP / PES / PTFE Pleated
POWER PLANT
High efficiency filtration for condensate, boiler feed water and other critical systems.
Recommended:
High Area Pleated Cartridge
Common problems we help solve
Fast pressure drop increase
Short cartridge service life
Frequent replacement
Inconsistent filtration efficiency
Mismatch with existing housing
Need for brand-compatible replacement
Our solution
Larger pleated filtration area
Stable pressure drop and longer life
Multiple micron ratings for different needs
DOE / 222 / 226 end cap options
OEM dimensions and brand replacement available
Strict quality control, reliable performance
Pleated Depth Filter Cartridges
Prefiltration, high solids loading, downstream protection.
Pleated Membrane Filter Cartridges
Fine filtration, final filtration, controlled retention.
High-Capacity Pleated Filter Cartridges
Higher dirt-holding capacity, stable differential pressure, longer service life.
Compatible replacement
Compatible with major brands.OEM dimensions and end caps available
FAQ
How do I choose between PP and PES pleated cartridges?
PP is suitable for general water treatment, RO pretreatment and chemical prefiltration. PES is preferred for finer filtration, high-purity liquids and food or beverage applications.
What micron rating should I use before RO membranes?
1–5 μm is commonly used before RO membranes. The final choice depends on feed water quality, SDI, turbidity and acceptable pressure drop.
Can you match 222 / 226 / DOE end caps?
Yes. We can supply DOE, 222 and 226 end caps, including flat and fin-end options. Please provide your existing filter photos or model number for confirmation.
Can you replace my existing Pall or Parker cartridge?
Yes. We can help cross-reference Pall, Parker and other filter models based on dimensions, end caps, seals, media and micron rating.
Do you support OEM dimensions?
Yes. We support customized length, outside diameter, end caps, O-ring materials, filter media, micron rating, labels and packaging.
What information is needed for a quotation?
Please send the application, liquid type, micron rating, cartridge length, end cap, seal material, operating conditions, quantity and existing model or photo.
Why choose us
15+ Years Filtration
Manufacturing Experience
Advanced Production
and Test Equipment
Strict Quality Control
ISO 9001 Certified
Fast Delivery and
Global Service
REQUEST A QUOTE
Submit your requirements, our engineers will provide the best solution for you.
